In todays video we take a look at the different Ethernet categories, explain what they are and then go on to look at the wiring formats and make our own cable & test that it works.
Baldrick Input 8 – Introduction & Demo
If you really want to put smiles on faces then audience participation is the way to go! The Baldrick Input 8 is an easy to use method to add buttons to either a standalone self prop or to drive FPP for full show control !
Repairing Pixel Strings
What happens when a pixel in a string goes wrong ?
In this video we demonstrate the replacement of failed pixels on a string used on my house.
We show a connectiivty oddity, prove a failed pixel and why we would often cut that pixel & the one prior to it & then we spilce a couple of new pixels in using some solder seals to complete the task.
Tools of the Trade: The Multimeter
In this first video in a new mini-series, we look at some of the tools a Newbie to the hobby will find useful.
The humble multimeter is a vital addition to the toolbox and can help in a multitude of ways as we find out.
xLights Advanced Moving Heads
This week we take a look at the Moving Heads Advanced models & effect in xlights.
We run through adding a new Baldrick DMX controller, adding two different moving heads & the differences in their setup and then we get them running together in a short sequence to finish.
Setting up a DMX Moving Head via a Falcon F16v4 and using xLights 2025_08
This week we’re looking at how to configure a DMX moving head fixture in xLights & drive it via the DMX port on a Falcon F16 v4. We run through the wiring, configure the model – push the configuration to the F16 and finish up with some basic tests to confirm the fixture does what […]
Wiring your first Pixel Controller, Pixels & Power Supply
In this video we run through the basic wiring of a set of pixels, a Baldrick controller and a Meanwell RSP-320-12 12v Power Supply. We hook them all up detailing what we’re doing and why and run a test mode on the pixels at the end of the video.
Pixel Lighting – what do I need to get started ?
In this video we cover the basic hardware needed to get your lights working,
A quick overview of Pixels, Controllers & Power Supplies.
Baldrick Switchy – Overview, xLights Setup & Demo
Here we run through the Baldrick Switchy relay board & demo its config, setup with xLights and demonstrate a running sequence with actions on the relay board.
4 Wire Pixels – Are they worth it ?
This week we look at 4 wire pixels, explain how they work & demonstrate fail over.
As they are native 12v we also look at the power consumption vs regular 12v WS2811 3wire resistor pixels.
0:00 Introduction
0:42 How does a Traditional WS2811 3 Wire Pixel Work ?
3:20 3 Wire Pixel Failure Demo
4:40 How does a 4 Wire GS8208 Pixel Work ?
10:15 4 Wire Pixel Failure Demo
12:08 Review of Resilience
12:35 Native 12v Power Consumption vs 12v WS2811 Resistor Pixels
16:00 Conclusion
